MBR Wastewater Treatment Equipment

Pure Water Process AO+MBR Wastewater Treatment Plant 250L-10000L

Application :

♦Hotel,restaurant,community etc domestic sewage treatment recycle
♦Industrial and mining enterprises,remote village,sentry ,tourist area etc domestic sewage recycle.
♦Each kind of industrial sewage (similar to domestic sewage) : such as domestic sewage . hospital sewage,pharmaceutical sewage,washing sewage,food sewage etc

PRODUCT DETAILS

PRODUCT ADVANTAGES

THE TREATMENT EFFECT IS OBVIOUS

After sewage treatment,it can be used for greening,toilet and other reclaimed water reuse

Application

Membrane bioreactor (MBR) is a new and efficient wastewater treatment technology which combines membrane separation and biological treatment. The denitrification mechanism of industrial nitrogenous wastewater includes two basic processes: nitrification and denitrification. Nitrification refers to the process of converting ammonia nitrogen into nitrate nitrogen, which is mainly completed by two types of aerobic autotrophic bacteria, nitrifying bacteria and nitrifying bacteria.

MBR membrane technology first by activated sludge removal of biodegradable organic pollutants in water, and then USES the membrane component force intercept the activated sludge bioreactor and the vast majority of suspended solids, implementation after purification of water and activated sludge solid-liquid separation, thus strengthened the biochemical reaction, improve the effect of the sewage treatment and water quality.

The MBR process has a significant effect on COD treatment in the wastewater of nitrogen fertilizer industry, and its biochemical strain regimen and acclimation stage is short, showing a stable effect from the third day. In stable treatment stage and normal operation stage, the COD removal rate can maintain high, and the removal rate is more than 90%. The average COD for export should be controlled below 30mg/L.

REAL SHOT DISPLAY

COMPANY REAL SHOW

Chengdu Yuanjin Environmental Protection Engineering Co., Ltd. was established in 2012 with a registered capital of 20 million. The production workshop covers an area of 1,400 square meters. There are more than 20 employees, including 2 senior engineers, 4 intermediate engineers, and 14 professional technicians; our company's technical team, all It is composed of a group of people who have worked in the field of water treatment for a long time. The company is a high-tech enterprise. It has obtained a number of certificates such as a patent certificate, nine software copyrights, a construction enterprise qualification certificate, and ISO9001 international quality management system certification. The environmental protection project will strive to build the most well-known Chengdu water treatment company. We have always adhered to the tenet of "quality first, customer first" and the management policy of "integrity, pragmatism, responsibility and efficiency", and advocated new ideas and new technologies. Tolerance for failure is the company's philosophy, which ensures that every employee of our company can pay for the company wholeheartedly, and that every one of our customers is satisfied with the services provided by the company.

Chengdu Yuanjin Environmental Protection Engineering Co., Ltd. is located in Tianfu New District, a national new district in Sichuan Province, and Chengdu Yida Tianfu Smart Science and Technology City. The company has a group of professional technical teams engaged in water environment treatment for a long time, which can provide targeted design schemes. Its own production workshop directly manufactures equipment according to the design requirements, and the prefabricated equipment in the workshop is directly sent to the construction site for installation and commissioning. It is an environmental protection supplier that can provide professional environmental protection equipment manufacturing and housekeeping technical services in design, manufacture, installation, commissioning and operation.

The company is a high-tech enterprise, with professional contracting qualification of environmental protection engineering, second-class qualification of domestic sewage and automatic monitoring operation ability, 7 national authorized patents, 9 computer software copyrights, ISO quality management certification system and other qualifications and honors.

The water treatment equipment produced by the company covers domestic sewage, medical wastewater, landfill leachate, reclaimed water reuse, pure water preparation and other fields, which can meet the national, local and industrial discharge and use standards and different needs of customers.

The company has four series of integrated sewage treatment equipment, namely AT·Jin sewage treatment integrated reactor, DT·Jin sewage treatment integrated reactor, PT·Jin sewage treatment integrated reactor and MINI·Jin sewage treatment integrated reactor. Prefabricated pumping station, reclaimed water reuse and pure water preparation are all systems.

AT·Jin sewage treatment integrated reactor is a series of products adopting "AAO+ tubular membrane" process. After biochemical treatment, sewage enters the third generation external ceramic tubular membrane, and under certain pressure, macromolecular particles larger than 0.1 micron are trapped by the nano-pore filtration function of the membrane. The flux of tubular membrane is 3~10 times that of organic membrane, and its service life is 10 years, which is 3~5 times that of organic membrane.

DT·Jin sewage treatment integrated reactor is a series of products adopting "AAO+MBR" process. After anaerobic, anoxic and aerobic biochemical treatment, the sewage enters the built-in MBR membrane pool for membrane filtration, and the hollow fiber membrane wall is covered with micropores. Under the action of aeration, the sewage accelerates to flow outside the hollow fiber, and forms dynamic negative pressure filtration under the suction of self-priming pump, which does not block the membrane surface and can run continuously for a long time. Macromolecular particles are trapped in the micropores of the membrane, and clear water enters the membrane filaments through the micropores, and is pumped into the clear water pool by a self-priming pump.

PT·Jin sewage treatment integrated reactor, first of all, through biochemical treatment in anaerobic tank and aerobic tank, biological filler is added into aerobic tank, bacteria micelle, filamentous bacteria, etc. grow into microcolony on the filler, and finally a biofilm with a certain thickness is formed. The oxygen content inside and outside the biofilm is different, which produces nitrification and denitrification to purify sewage. The biofilm will gradually fall off after aging, and the released bacteria will form a new biofilm on the surface of the filler again, and the biochemical cycle treatment will continue. After that, chemical dephosphorization is added to the effluent, which enters the inclined tube sedimentation tank to effectively separate the mud and water.

MINI·Jin sewage treatment integrated reactor, with small equipment size, flexible layout of internal space and various shapes, is a small equipment for rural sewage treatment.

The integrated pumping station is the lifting equipment for lifting sewage, rainwater, drinking water and wastewater, which is assembled by the factory and then transported to the site for installation. With highly integrated equipment, convenient installation and prefabricated workshop, it is gradually replacing the traditional civil pump house, which is the second generation of high-efficiency and energy-saving products.

The preparation of pure water and the reuse of reclaimed water are treated by ultrafiltration and reverse osmosis processes. According to the application approaches and standard requirements, single membrane, double membrane, one-stage and multi-stage configurations are carried out, which are used in high-standard fields such as drinking water and industrial soft water.

The water treatment equipment produced by the company is equipped with PLC control system, which can realize remote control and unattended operation, thus saving worry and effort for customers.

The company's integrated water treatment equipment, installation and operation projects are widely used in the southwest and northwest regions. In the past three years, the annual output value has increased by more than 10 million yuan, which has established a good reputation in the industry. Chengdu Yuanjin Environmental Protection Engineering Co., Ltd. adheres to the business philosophy of "focusing on sewage treatment, reappearing clear water and clearing the source", constantly improves its professional ability, develops and updates its product series, improves its quality service, and strives to build a first-class brand in the industry, helping the construction of national ecological civilization and guarding our common home!
